Make/ Model: ATLAS 270MH

Year of Manufacture: CE Plated 2020

Op Weight: 29,500 Kg

Max Outreach: 14.65 metre

Approx. Hours: Genuine low hours – 2,308

Attachment: Atlas E751 600 litre half closed five tine orange peel

Machine Spec Includes: 1 x generator mount set & 1 x R-mag generator

Key Specification Includes:

ATLAS 270MH base unit with Tier 4 Final engine, four outriggers, proportional hydraulic reversing fan drive, standard Cummins cyclone type air filter, heated air suspension seat with head rest, roller blind for front screen, camera system for rear and right hand side views.

  • C25.6I Industrial monoboom (working length 8000 mm)
  • D25.16I Industrial stick (working length 6000 mm, stick width 345 mm, bolt diameter 80 mm)
  • Cab with hydraulic lift to 2.5 m
  • Super elastic tyres, maximum speed 16kph
  • Hose rupture valves for two stick cylinders
  • Auto shut-off for arm extension & retraction
  • Hydraulic kit, for generator, 100 l pressure maintenance valve
  • Track unit telematics unit for machine data transmission or machine location
  • Central lubrication system
  • Red & white chevrons on counterweight and hi viz decals on stabiliser legs
  • Extra step x 1 at undercarriage on fixed axle side (i.e. rear axle)
  • Boxing ring
  • Smart white noise travel alarm
  • Seatbelt in use system with pole & green roof mounted beacon
  • One LED Rotating beacon on top of the cab
  • Four LED work lights on front cab
  • Two LED work lights on industrial stick
  • One LED work light on Industrial boom
  • Complete radio installation with AUX interface, USB and Bluetooth
  • Cab protective guard for front screen and roof

Remaining Platinum Warranty Applicable when machine based within the UK:

Approx 18 months or approx. 3,694 hours (whichever is the sooner) platinum warranty.

Availability: June/July 2023 – Subject to prior sale.

Service History: Fully serviced by TDL Equipment at 500 hour intervals.

Atlas 270MH Selling Price Excluding Delivery : £195,000.00 + VAT
